Tools Page 3

TOOLS - LAPPING & POLISHING TOOL JMW 1587

Graver mounted ready for sharpening.

Graver mounted ready
for sharpening
.

Sharpening the Graver.

Sharpening the Graver.

Fly Cutter ready forsharpening - tool inverted.

Fly Cutter ready for
sharpening - tool inverted
.



Designed to impart a flat and true polished finish to all small cutting tools. Suitable for finishing fly cutters, gravers, small drills.
The Polishing Tool is held in the bench vice when being operated. The tool being sharpened is first ground to shape on a hand grinder
and then transferred to the Lapping and Polishing Tool. Two holders are supplied, one for square tools and the other for round.

Polishing is achieved by laps held in guides that have two grades of diamond shim bonded to them. The final finish is with a fine grade ceramic stone. This imparts a highly polished finish to the cutting edge of the tool, which in turn will transfer this finish to the work being cut.

There is virtually no limit to angled cutting faces that can be polished as both the lap and tool holder can be rotated through 360'. Facility is also included for the lap holder to rotate on the main body.

SMALL DIAMETER TURNING TOOL JMW-1583

SMALL DIAMETER TURNING TOOL JMW-1583 In use  - SMALL DIAMETER TURNING TOOL JMW-1583

Suitable for use on most of the popular small to medium sized lathes (typically 3 - 6" centre height) it is easily mounted on quick change tool holders, as well as turret tool holders and by conventional tool clamping methods.

Designed for turning diameters as small and as long as required from standard stock in one pass.

The updated design above has a built in additional height adjustment.

Ideal for turning arbors for clocks.

Supplied with blank bushes for drilling to suit bar size, complete with H.S.S. cutting tool.
